This type can do can-feeding, measuring, filling and exhausting work. it fits to the fluidic or low-fluidity materials, like milk powder, gourmet powder ,solid drink, white sugar, dextrose, coffee, fodder , solid medicine, granularity additive, dyestuff, and so on.
ZHG-50F
ZUNGWAN
| Availability: | |
|---|---|
| Quantity: | |
Brief introduction:
This machine is suitable for 2-500g material circular flat plastic or glass bottles of powder filling capping. This machine is made of high precision cam indexing mechanism to provide indexing equal-dividing disk positioning plug cover; acceleration cam drive provides capping head lifting; constant torque capping; high precision screw metering filling; without touch screen control. Bottle filling, without inner plug, the outer cover. With accurate positioning, stable transmission, protective cap, accurate in measurement. The advantages of simple operation, fully in line with the new GMP requirements of the national.
Characteristic.
Computer control, accurate, convenient operation of installed capacity.
The engine speed can be stepless variable speed.
Production of automatic quantitative control.
Multiple fault prompting function.
Automatic shutdown function, appear continuously without filling cases can be automatically shut down.
The appearance of the use of SUS304 stainless steel easy maintenance.
316L stainless steel screw filling, corrosion resistance strong.
This equipment is in full compliance with the new GMP requirements
Technical parameters:
Applicable specifications 2-500g
Production capacity of 20-50 bottle / min
Filling precision is less than or equal to + 1%
Power 220V / 50Hz
Rotary ( rolling ) cover rate of more than 99%
Automatic plug rate > 99%
Gas 1.3 m3 / h 0.4-0.8Mpa
Power 2 kW
Machine net weight 500 kg
Size of 2200 * 1000 * 1600mm
