ZHGP-30 Automatic Spray Bottle Filling and Capping Machine

The ZHGP-30 Automatic Spray Bottle Filling and Capping Machine is designed for filling liquid products into compatible spray bottles and completing the associated spray-pump or cap placement and capping processes.

The published filling range is 15–150 ml. Final compatibility depends on the bottle dimensions, neck finish, spray-pump construction, dip-tube length, cap style, liquid properties, and required production output.

The machine uses a PLC-controlled production process and can be configured around the customer’s packaging components. Depending on the ordered line configuration, bottle feeding, labeling, and coding equipment may also be integrated.

Integrated Spray Bottle Packaging Process

Bottle Infeed

Empty bottles enter the machine through the configured feeding and conveying system. Bottle guides, holders, or positioning components keep each container aligned as it moves between operating stations.

A bottle unscrambler may be connected where bulk automatic bottle feeding is required. Whether this equipment is included should be confirmed in the final machine configuration.

Controlled Liquid Filling

Bottles are positioned below the filling nozzles before the measured liquid is dispensed. The filling volume and operating speed are adjusted through the control system according to the selected container and product.

The correct filling method must be selected around the liquid’s viscosity, foaming tendency, chemical compatibility, and required accuracy.

Spray-Pump or Cap Placement

After filling, the applicable spray pump, actuator, or closure is placed onto the bottle. The feeding and placement system must match the actual closure geometry.

Spray-pump components should be tested because actuator shape, collar diameter, dip-tube length, and orientation can affect automatic feeding and insertion.

Capping

The capping station secures the closure using tooling matched to the supplied spray pump or cap.

Capping pressure, height, speed, and torque should be adjusted during commissioning. Excessive force can deform the closure or damage the bottle neck, while insufficient force may produce loose caps or leakage.

Finished-Bottle Discharge

Completed bottles are discharged to the next operation. Depending on the production line, this may include labeling, coding, inspection, cartoning, or accumulation.

Liquid Filling Control

15–150 ml Filling Range

The published applicable range is 15–150 ml. This range covers many small and medium spray-bottle formats used for cosmetic, personal-care, household, and compatible liquid products.

Filling range alone does not confirm machine suitability. Bottle stability, neck dimensions, liquid behavior, and closure design must also be evaluated.

Filling Accuracy

The published filling accuracy is within ±1 ml. Actual results should be confirmed using the intended liquid, filling volume, operating speed, and production environment.

For small fill volumes, an absolute tolerance of ±1 ml may represent a significant percentage of the total dose. Customers with tighter requirements should provide their permitted tolerance before the machine is configured.

Liquid Compatibility

The ZHGP-30 can be evaluated for free-flowing sprayable liquids such as:

• Facial mist

• Hair-care spray

• Body spray

• Air freshener

• Non-aerosol disinfectant spray

• Household cleaning spray

• Fabric spray

• Compatible fragrance products

• Other low-viscosity sprayable liquids

Products containing suspended particles, abrasive ingredients, aggressive solvents, high alcohol concentrations, or corrosive chemicals require a separate material-compatibility review.

The machine is not automatically suitable for pressurized aerosol filling.

Filling-System Selection

The original product information does not specify the standard pump or metering method. Depending on the product, suitable systems may include peristaltic, piston, ceramic, or other metering technologies.

The final filling system should be selected after reviewing:

• Liquid viscosity

• Foaming tendency

• Fill volume

• Required accuracy

• Cleaning method

• Product-contact material

• Production speed

• Cross-contamination requirements

Spray Pump and Cap Handling

Closure Matching

Spray pumps vary considerably in actuator shape, collar diameter, thread design, dip-tube length, and feeding behavior. Closure tooling should therefore be designed around actual customer samples rather than nominal cap diameter alone.

Before production, confirm:

• Bottle neck diameter

• Neck finish and thread

• Pump collar dimensions

• Actuator shape

• Dip-tube length

• Cap material

• Required tightening method

• Permitted application torque

Dip-Tube Control

Long or curved dip tubes can interfere with automatic insertion. The feeding mechanism must guide the tube into the bottle without bending, trapping, or damaging it.

Customers should supply representative pumps with the final production dip-tube length for machine testing.

Capping Stability

The page publishes a capping rate of at least 99%. This result depends on stable closure feeding, consistent bottle dimensions, correct tooling, suitable torque, and properly manufactured packaging components.

A sample run is recommended to verify cap engagement, pump orientation, leakage, and finished-bottle appearance.

Different Closure Types

The machine may be configured for compatible screw-on spray pumps or caps. Press-on, crimped, snap-fit, tamper-evident, or unusually shaped closures may require different equipment or additional stations.

Closure type must be confirmed before the capping system is selected.

Bottle and Format Changeover

The ZHGP-30 can be configured for different compatible spray-bottle formats within its applicable range. Changeover may involve adjusting or replacing:

• Conveyor guides

• Bottle holders

• Filling-nozzle height

• Pump-placement tooling

• Closure-feeding components

• Capping heads

• Labeling parameters

• Sensors and bottle-position settings

Using several bottle formats on one machine is possible only when their dimensions and closure structures fall within the machine’s designed adjustment range.

Customers planning frequent changeovers should provide every intended bottle, pump, and cap combination during project evaluation.

Labeling and Coding Integration

The original product page describes vertical labeling and thermal coding functions. These functions should be confirmed as standard, integrated, or optional equipment when ordering.

Labeling

A labeling unit can be configured for compatible self-adhesive labels. Label dimensions, bottle shape, label position, and required application accuracy must be supplied before selection.

Stable label application depends on a sufficiently consistent bottle surface. Highly tapered, flexible, oval, or irregular containers may require special positioning.

Coding

Coding equipment may be added for information such as:

• Batch number

• Production date

• Expiration date

• Product code

• Traceability information

The suitable coding method depends on the bottle or label material, print position, line speed, and required print durability.

Control and Operation

PLC and Touch-Screen Control

The ZHGP-30 uses PLC-based control with a touch-screen interface for managing the coordinated production process.

Applicable settings may include:

• Filling volume

• Filling delay

• Conveyor speed

• Bottle positioning

• Pump-placement timing

• Capping timing

• Operating speed

• Fault reset

• Manual testing of individual stations

The available interface language, recipe storage, alarm records, and access-control functions should be confirmed for the ordered configuration.

Adjustable Production Settings

Machine settings can be adjusted around the bottle, liquid, spray pump, and required output. Production speed should be established through sample testing rather than determined from bottle volume alone.

Sensors and Interlocks

Bottle and component sensors help coordinate filling and capping operations. Functions such as no-bottle-no-fill, missing-pump detection, cap detection, and discharge monitoring should be confirmed in the technical specification.

Safety guards, emergency stops, electrical protection, and machine interlocks must be checked before operation.

Applications

Cosmetic and Personal-Care Sprays

The machine can be configured for facial mist, toner spray, body spray, hair-care products, and other compatible personal-care liquids.

Product-contact materials should be reviewed for formulas containing alcohol, fragrance oils, active ingredients, or solvents.

Household Cleaning Sprays

Compatible household cleaners, surface sprays, fabric sprays, and deodorizing products may be filled when the formula is suitable for the selected metering system and contact materials.

Corrosive or strongly oxidizing products require a separate assessment.

Disinfectant Spray Products

The ZHGP-30 may be evaluated for compatible non-aerosol disinfectant liquids. Flammable alcohol-based formulations require additional electrical, ventilation, and explosion-risk assessment.

Air Fresheners

Free-flowing air-freshener liquids can be filled into compatible pump-spray bottles. Fragrance formulas should be checked for seal, hose, gasket, and pump compatibility.

Pharmaceutical and Healthcare Packaging

The machine may handle certain spray-bottle formats used for healthcare products, but this does not by itself establish sterile, aseptic, GMP, or pharmaceutical regulatory compliance.

The customer remains responsible for defining the required cleanroom, validation, documentation, material, and regulatory conditions.

Production-Line Configuration

The ZHGP-30 may be combined with upstream and downstream equipment according to the required level of automation.

Possible equipment includes:

• Automatic bottle unscrambler

• Bottle infeed table

• Spray-pump or cap feeder

• Labeling machine

• Date or batch coder

• Vision inspection

• Reject mechanism

• Cartoning machine

• Case packing equipment

• Finished-product collection table

Line controls, conveyor height, communication signals, operating speed, and product accumulation should be coordinated during engineering.

Information Required for Machine Selection

To prepare the machine configuration, provide:

1. Bottle samples and dimensional drawings

2. Spray-pump and cap samples

3. Dip-tube length

4. Liquid description and safety data

5. Required filling volume

6. Permitted filling tolerance

7. Target production output

8. Label dimensions and application position

9. Required coding method

10. Available voltage, frequency, and compressed-air supply

11. Required contact materials

12. Cleaning and changeover requirements

Representative production samples are recommended before final tooling is manufactured.

Technical Specifications

Specifications may change according to the customer’s packaging samples, product characteristics, and production-line requirements.

Configuration and Engineering Support

ZUNGWAN can review the customer’s bottle, spray pump, cap, liquid, label, and production requirements before preparing a machine configuration.

Project support may include:

• Bottle and closure evaluation

• Filling-system selection

• Tooling design

• Sample testing

• Production-line layout

• Labeling and coding integration

• Electrical configuration

• Installation guidance

• Operator training

• Spare-parts planning

Customers should request a final technical specification, machine layout, approved sample record, utility list, and configuration sheet before placing an order.

FAQs

What bottle sizes can the ZHGP-30 handle?

The published filling range is 15–150 ml. Bottle height, diameter, shape, neck finish, and stability must also fall within the configured machine range.

Can the machine handle different spray pumps?

It can be configured for compatible spray pumps, but each pump design must be evaluated. Actuator shape, collar diameter, thread, dip-tube length, and feeding orientation affect compatibility.

Is the production capacity 3,000 bottles per minute?

The original page lists 3,000 bottles per minute, but this unit requires confirmation. Actual output should be specified in the final technical agreement after testing the bottle, liquid, pump, and filling volume.

What filling system does the machine use?

The original page does not clearly identify the standard metering system. The filling method should be confirmed and selected according to the liquid, volume, accuracy, and cleaning requirements.

Can it fill high-alcohol products?

Compatibility depends on the alcohol concentration, product-contact materials, electrical design, ventilation, and applicable explosion-protection requirements. The formula and safety data should be reviewed before selection.

Can it fill viscous liquids?

The machine is primarily presented for sprayable liquids. Higher-viscosity products may require a different filling pump, larger nozzle, lower speed, or a separate machine configuration.

Are labeling and coding included?

The page describes labeling and thermal coding, but their standard or optional status should be confirmed in the quotation and technical specification.

Can one machine run several bottle sizes?

Multiple formats may be possible when their dimensions and closure designs are within the machine’s adjustment range. Change parts or separate tooling may be required.

Does the machine automatically feed spray pumps?

Automatic pump feeding may be configured, but feasibility depends on pump geometry and dip-tube behavior. Samples are required for evaluation.

Is this an aerosol filling machine?

No. The ZHGP-30 is described as a liquid filling and capping machine for pump-spray bottles. Pressurized aerosol products require dedicated aerosol filling equipment.

Is the machine GMP compliant?

The original page claims GMP compliance but does not provide the applicable standard, qualification documents, or configuration conditions. Pharmaceutical suitability must be assessed against the customer’s actual regulatory and validation requirements.

What should be tested before shipment?

Testing should cover filling accuracy, bottle positioning, pump insertion, cap engagement, leakage, operating speed, label placement, coding quality, changeover, and fault response using representative production samples.
